Technical Specification:-
| Max. test force |
3000 KN |
Force range |
300 ~ 3000 KN |
Testing space |
280 x 280 x 80 ~ 450 mm |
Piston max. stroke |
50 mm |
Readout accuracy |
≤±1% |
Motor power |
0.75kW |
Machine size |
950 x 560 x 1200~1570 mm |
Approximate weight |
1000Kg |
Calibration Accuracy grade |
Class one (I) |
Rated voltage |
~220V±10%V, 50Hz |
Working temperature |
0~40 |
Power consumption |
≤30VA |
Printer |
Printer can be connected |
Warranty: One year from the date of supply. (Remark: this service excludes consuming parts. And FTM reserves the right to reject those claims for warranty where the failure is caused by the modification made by buyer, improper maintenance, misuse, or abuse of the equipment). And over-green service.
