Technical Specification:-
| Max. test force |
2000 KN |
Force range |
200 ~ 2000 KN |
Testing space |
240 x 240 x 80 ~ 450 mm |
Piston max. stroke |
50 mm |
Readout accuracy |
≤±1% |
Motor power |
0.75 kW |
Standard |
Comply with ISO, BS, ASTM and EN or other standards.ASTM E4, EN12300-5, ISO7500, ISO6892, and BS4449:1998 |
Machine size |
850 x 500 x 1480 mm |
Approximate weight |
800Kg |
Calibration Accuracy grade |
Class one (I) |
Rated voltage |
~220V±10%V, 50 Hz |
Working temperature |
0~40 |
Power consumption |
≤30VA |
Printer |
Printer can be connected |
Warranty: One year from the date of supply. (Remark: this service excludes consuming parts. And FTM reserves the right to reject those claims for warranty where the failure is caused by the modification made by buyer, improper maintenance, misuse, or abuse of the equipment). And over-green service.
